Info Presse Division Colles
Colles spéciales pour les systèmes de contact cellulaire
Eleco-Panacol a développé des colles UV spéciales qui protègent de la corrosion les soudures des systèmes de contact des cellules et des batteries des voitures électriques. Ces colles résistantes aux vibrations sont très souples avec une grande pureté ionique.
Les systèmes de contact de cellules à haute performance (CCS), qui combinent des cellules individuelles de batterie au lithium-ion pour les véhicules hybrides et électriques afin de former des blocs de batterie, sont souvent connectés et soudés par des fils ou filaments. Pour protéger ces joints soudés de la corrosion, Panacol a mis au point des colles UV spéciales à faible teneur en ions qui sont appliquées comme revêtement protecteur. Celles-ci fournissent une caractéristique mécanique additionnelle lorsqu'elles sont soumises à des vibrations et peuvent compenser la dilatation thermique des différents matériaux.
Les colles UV Vitralit® UV 2113 et Vitralit® UV 2114 se caractérisent par une très forte adhérence sur de nombreux matériaux et répondent aux exigences de l'industrie automobile en termes de résistance aux contraintes et à la température. Les propriétés rhéologiques de Vitralit® UV 2113 et Vitralit® UV 2114 peuvent être adaptées aux besoins individuels des clients. Des variantes des colles fluorescentes pour le contrôle des processus optiques sont également disponibles.
En quelques secondes seulement, les colles susmentionnées peuvent être durcies par la lumière UVA ou lumière visible. Les lampes UV à décharge et les spots UV à LED peuvent être utilisés pour la polymérisation. Les systèmes UV et LED UV de Dr. Hönle sont parfaitement adaptés aux colles Panacol, par exemple le système de haute intensité LED Powerline AC/IC HP.
Pour les géométries CCS complexes avec des zones cachées, Vitralit® UD 8050 est une colle à base d'acrylate à double durcissement. Après une polymérisation UV cette colle de grande pureté ionique continue de durcir avec l'humidité de l'air dans les zones cachées où les UV ne peuvent passer.
Contactez-nous pour obtenir les fiches techniques
Colle biocompatible résistante à des températures élevées
La colle époxy Vitralit® 1605 est particulièrement unique en raison de sa température de transition vitreuse élevée ce qui permet de l’utiliser pour les applications avec des températures élevées. La colle biocompatible polymérise sous la lumière UV et convient à l'assemblage de dispositifs médicaux.
La colle monocomposant Vitralit® 1605 à base de résine époxy est transparente et très facile à déposer. Grâce à son excellente adhésion sur le verre et le métal, elle peut être utilisée pour fixer des lentilles en verre et des lentilles cylindriques dans les endoscopes ou encore pour coller des couplages de lentilles, par exemple.
La Vitralit® 1605 cationique peut être durcie sous la lumière UV dans la gamme de longueurs d'onde de 320 nm à 390 nm. Elle est également dotée d'un initiateur thermique qui permet un durcissement secondaire des zones cachées. Les lampes UV de la société Dr. Hönle AG sont parfaitement adaptées à cette colle et permettent des processus de durcissement rapides et constants.
Lorsqu'elle est entièrement durcie, la Vitralit® 1605 se caractérise par une excellente résistance chimique et un très faible retrait. En outre, elle présente une température de transition vitreuse très élevée de 150 °C et un faible coefficient de dilatation thermique. Cela permet de coller les composants qui nécessitent une stabilité maximale à des températures de fonctionnement élevées. En outre, Vitralit® 1605 peut résister aux processus de stérilisation habituels. En raison de ces caractéristiques, ainsi que de sa certification selon la norme ISO 10993-5, Vitralit® 1605 est particulièrement adaptée au collage dans la technologie médicale.
Contactez-nous pour obtenir les fiches techniques
Gennevilliers, 27 mars 2020
Nouvelle colle thermo-conductrice pour les composants sensibles à la chaleur
La nouvelle colle Elecolit® 6607 d‘Eleco-Panacol est thermo-conductrice et peut être polymérisée à des températures basses à partir de 80°C. Elle se caractérise par une excellente adhérence sur le métal et est isolante électrique.
Elecolit® 6607 est une colle à base de résine époxy chargée d'oxyde d'aluminium. Il s'agit d'une colle mono composant qui, grâce à ses propriétés d'écoulement, peut être appliquée facilement avec doseur, par sérigraphie ou encore avec une spatule.
Elecolit® 6607 durcit à basses températures dès 80°C, les composants sensibles à la chaleur peuvent être utilisées. Des températures de polymérisation plus élevées raccourcissent le temps de durcissement.
Après durcissement, la colle de couleur grise claire isole électriquement et assure en même temps une excellente dissipation de la chaleur. Grâce à ses propriétés, Elecolit® 6607 est particulièrement adaptée au collage de composants métalliques et de dissipateurs thermiques sur les cartes de circuits électroniques.
Contactez-nous pour obtenir les fiches techniques
Elecolit® 6607 durcit à basses températures dès 80°C
Gennevilliers, 13 février 2020
Nouvelle colle autoclavable pour les revêtements
La nouvelle colle UV Vitralit® 2028 d’Eleco Panacol – EFD est résistante aux produits chimiques et se caractérise par un revêtement autoclavable. En tant que résine de coulée flexible, elle est polyvalente et peut être polymerisée par lumière UV et post-polymerisée thermiquement.
La résine époxy transparente Vitralit® 2028 peut être facilement dosée grâce à sa faible viscosité. Elle est donc parfaitement adaptée en tant que composant de revêtement flexible.
Vitralit® 2028 polymérise par la lumière UV avec une longueur d’ondes de 320 nm à 390 nm. Les lampes UV de la société Dr. Hönle AG garantissent des résultats de séchage parfaits. La particularité de cette colle est qu'elle possède un initiateur thermique qui permet un post-durcissement des zones d'ombre dans le four.
La colle est déjà très sèche après le séchage UV, de sorte que le composant peut être traité directement. La résistance finale de la colle est obtenue lorsque le revêtement refroidit. Vitralit® 2028 est transparente et, après polymérisation complète, elle résiste aux produits chimiques et peut être passée à l'autoclave. Ce matériau est idéal comme revêtement protecteur pour les fils dans les enroulements de bobines et pour d'autres applications nécessitant des revêtements protecteurs.
Vitralit® 2028 est idéal comme revêtement protecteur pour les fils dans les enroulements de bobines
Gennevilliers, 20 janvier 2020
Nouvelle colle UV à faible teneur en halogène
Avec Vitralit® UC 1536, Eleco-Panacol lance une autre colle à faible teneur en halogène pour l'industrie électronique. En raison de sa faible teneur en ions, elle convient parfaitement au traitement des semi-conducteurs. Cette nouvelle colle transparente avec surface brillante est polymérisée en quelques secondes.
La colle Vitralit® UC 1536 est une base époxy durcissant très rapidement sous la lumière UV. Sa stabilité la rend particulièrement adaptée aux applications qui nécessitent une stabilité dimensionnelle dans le processus de production.
La colle peut être durcie en quelques secondes par la lumière dans la gamme UVA de 320 nm à 390 nm. Grâce à nos équipements UV fabriqués par notre groupe Hönle, des solutions sur mesure pour la polymérisation de la Vitralit® UC 1536 sont disponibles pour chaque application.
Après durcissement, Vitralit® UC 1536 présente une surface optiquement claire et brillante, très dure et donc résistante aux rayures. La colle reste résistante au jaunissement, même à haute température, et conserve sa brillante transparence. Avec une très faible teneur en ions, Vitralit® UC 1536 est idéale pour fixer les semi-conducteurs. Elle est actuellement utilisée avec beaucoup de succès pour coller des lentilles verre sur des capteurs CMOS.
Vitralit® UC 1536 peut être utilisée pour coller des lentilles verre de minicaméras
Steinbach/Taunus, 15 November 2019
Fast curing epoxy adhesive enables high efficiency cosmetic packaging
The new epoxy-based adhesive Vitralit® UC 6025 from Panacol optimizes automated assembly processes. It can be applied and cured very quickly due to its accommodating dispensing properties.
Especially designed for the cosmetics industry, Vitralit® UC 6025 has an optimal viscosity for gap-filling applications. The one-component epoxy adhesive is odourless and easy to dispense. Its controllability and fast curing properties make Vitralit® UC 6025 suitable for applications requiring a high performance.
Vitralit® UC 6025 can be cured with UV or visible light in just a few seconds. The adhesive curing process can be further optimized by using UV/LED curing equipment from Dr. Hönle. The fluorescing version of the adhesive, Vitralit® UC 6025 F, allows in-line process control for maximum productivity.
Once cured, the adhesive has high adhesion to ABS, aluminium and glass. These properties and lack of odour make Vitralit® UC 6025 ideal for applications in the cosmetics industry. Application examples include bonding lipstick applicators or bottle lids.
New epoxy adhesive Vitralit® UC 6025 is the perfect bonding solution for high volume production of plastic packagings
Steinbach, 26 September 2019
New biocompatible adhesive for plastics fluoresces orange
A new orange fluorescent UV adhesive from Panacol is specially formulated for bonding plastics: Vitralit® 7311 FO is certified according to USP Class VI standards which makes it the perfect solution for bonding medical devices.
Vitralit® 7311 FO is a low viscosity, transparent acrylic adhesive that cures under UV or visible light. It offers very high bond strength to many plastics including PC, PVC, PMMA or ABS, and also to materials such as glass and stainless steel. Thanks to its very low viscosity and capillary flow characteristics, Vitralit® 7311 FO is suited for bonding large surfaces as well as applications with narrow gaps.
Under low intensity black light (365 nm wavelength), Vitralit® 7311 FO fluoresces orange. This allows in-line inspection for quality control. The bright fluorescence is highly contrasting with plastics possessing a natural blue fluorescence or color. Optimum curing results can be achieved with LED curing equipment with a wavelength of 405 nm, especially the UV-LED equipment Bluepoint LED eco from Hoenle. Bluepoint LED eco can be equipped with both wavelengths, serving both processes. Thanks to modern photo initiators Vitralit® 7311 FO can be cured – especially in high volume production – within seconds.
Once cured, Vitralit® 7311 FO is humidity and alcohol resistant. Vitralit® 7311 FO has been tested and certified according to USP Class VI standards. The product is compatible to common sterilization processes like autoclaving, gamma radiation, E-Beam or ETO and well suited for use in the assembly of disposable medical devices.
Panacol-Elosol GmbH, a member of the global Hoenle group, is an international supplier of adhesives with an extensive product range that includes UV curable adhesives, structural adhesives, and conductive adhesives. Panacol is also a reliable provider of UV processing systems, supported by Dr. Hoenle AG. Hoenle is a global technology leader and manufacturer of industrial UV curing devices and systems.
Steinbach/Taunus, 26 August 2019
New crystal-clear UV adhesive for semiconductor production
At this year’s BondExpo Panacol will present Vitralit® UC 1535, a new transparent adhesive specifically designed for use in electronics. It hardens with UV light within a few seconds and can be used for semiconductor production due to its low ion content.
The Vitralit® UC 1535 is an epoxy-based UV-curing adhesive that hardens very fast. It is easy to dispense and non shear-thinning. In just a few seconds, the adhesive can be cured with radiation in the UVA range from 320 to 390 nm. For a fast and efficient curing, the broad spectrum and UV/LED systems from Dr. Hoenle AG are highly recommended.
The adhesive was especially designed for the assembly and production of electronic and optomechanical components. For example, the new Vitralit® UC 1535 is being used to bond glass lenses in optical systems. Once cured the adhesive features a transparent, optically clear and brilliant surface, which is very hard and scratch-resistant. Vitralit® UC 1535 is non-yellowing and remains optically clear even when exposed to high temperatures. Because of its low ion content the adhesive can be used for semiconductor applications.
Visit us at the BondExpo in Stuttgart, Germany from the 7th to the 10th of October 2019 at booth 6420 in hall 6!
Vitalit® UC 1535 from Panacol is designed for the assembly and production of electronic and optomechanical components.
French company Eleco Produits – EFD, specialising in industrial adhesives, dispensing and uv curing equipment, and German based adhesives manufacturer Panacol-Elosol GmbH, are both members of the adhesives division within the Hoenle Group, headed by publicly listed company Dr. Hoenle AG. To better support the growth requirements of their global customers, and present a more unified product offering, Eleco Produits – EFD is changing its name to Eleco Panacol – EFD effective August 1, 2019. “With this decision we see synergies in marketing and global brand recognition for the Panacol Group”, explains Laurent Prevost, Managing Director of Eleco Panacol – EFD.
Eleco Produits – EFD has been specializing in the distribution of industrial adhesives and matching dispensing and curing equipment since 1974. Since the beginning, Eleco has been partnering with German adhesives manufacturer Panacol-Elosol, distributing uv, structural and conductive adhesives. Inhouse laboratories for quality control and adhesive applications allow in-depth testing and qualified consultation. Since 2008, Eleco has also been distributing matching uv curing equipment from new parent company Dr. Hoenle. To complement its all-in-one solutions, Eleco also provides dispensing equipment for its adhesives portfolio. Situated in the metropolitan Paris area, Eleco benefits from a central logistic hub. Effective quality control methods ensure high quality products, packaging and transport. Eleco is certified to ISO 9001 standards.
The focus of Eleco Panacol – EFD will remain on the sales of innovate industrial adhesives and equipment from its facility in Genevilliers/Paris. The organization’s management and team will remain intact.
Panacol-Elosol GmbH and Eleco Panacol – EFD, both members of the global Hoenle group, are leading suppliers of industrial adhesives, with a broad product range that includes uv curable adhesives and coatings, structural epoxies and conductive materials for electronics assembly.
Visit Panacol-Elosol: www.panacol.com
Visit Hoenle: www.hoenle.com
Eleco Panacol – EFD is headquartered in the metropolitan Paris area
Panacol developed a new optically clear adhesive: Vitralit® 50004. The new adhesive is a one-component uv curable acrylic adhesive with ultra-low viscosity, which is used for bonding displays and laminating optics.
Vitralit® 50004 adheres specifically to a variety of substrates including coated glass, PET and other plastics and films. It possesses a very low viscosity that facilitates fast filling of cavities without air entrapment. The adhesives cures quickly with minimal shrinkage for less residual stress between substrates.
Large-surface bonding or lamination of displays can be optimized by using Hoenle’s high-performance and energy efficient LED Spot 100 curing system which is perfectly matched to the photoinitiators of Vitralit® 50004.The alignment of the LEDs of the Spot 100 ensures high intensity and homogenous light distribution. The LED Spot 100 heads can be mounted together without gaps to match the size of the display being bonded.
Once cured, Vitralit® 50004 is very soft. Thermal stresses between dissimilar substrates can be neutralized without causing delamination. It’s high degree of flexibility enhances performance through repeated thermal excursions. The cured adhesive is optically clear and non-yellowing with excellent light transmission.
LOCA adhesives from Panacol are the perfect solution for serial production of displays and touchscreens
Panacol developed a variety of new adhesive products with low ion content which cure with uv light and moisture. These products were specially formulated for applications in the electronics and consumer electronics industry, where heat sensitive parts must be assembled.
Vitralit® UD 8050 is a one-component acrylic adhesive, which can be used as an encapsulant to protect electronic components on PCBs. Vitralit® UD 8050 can be cured with uv or visible light. Moisture postcuring ensures full cure in shadowed areas or deeper layers of the adhesive, which cannot be reached by light.
For specific requirements several versions of the adhesive are available: Vitralit® UD 8050 MV F allows enhanced flow control and focused dispensing on each component thanks to its shear-thinning behavior. Its low ion content prevents cor-rosion on electronic components. For superior process control Vitralit® UD 8050 MV F contains a fluorescent marker.
For jetting, the low viscosity version Vitralit® UD 8050 LV is the perfect solution. Thanks to its easy dispensing and fast curing Vitralit® UD 8050 LV is very conven-ient for applications in the production of consumer electronics where a high throughput is needed.
By default, the adhesive is transparent, but it is also available in blue or fluorescing versions. Other colors are available on request.
Blue uv-moisture curing adhesive is used as encapsulant for electronic components
New outstanding adhesives in Panacol´s product line are the thermosetting, one-component epoxy resin adhesives with very good heat-conducting properties and very high metal adhesion. These adhesives were specially formulated to meet the increasing demands for bonding and dissipating heat from power electronics.
Elecolit® 6603 for example is augmented with mineral-based fillers which ensure high electrical insulation. Comparable dielectric strength is usually only achieved by thermally conductive adhesive tapes. As an added benefit, the adhesive is resistant to constant heat stress up to 200° C.
Elecolit® 6603 is slightly flexible and can also be used as a potting compound. It features very good flow behavior and can be processed via screen printing, with a dispenser, spreading knife or a spatula.
Variations of this adhesive are available that offer greater rigidity and several selections of viscosity ranges. Depending on the individual application adhesives with higher heat conductivity or higher dielectric strength are available.
Thermally conductive adhesives from Panacol feature a wide range of characteristics
New Adhesive for Bonding Displays
Panacol introduces a newly developed acrylate adhesive for bonding displays. Vitralit® UD 8540 is very soft after curing, providing the ability to intercept thermal stresses between dissimilar substrates.
Vitralit® UD 8540 is a one-component, UV-curing acrylic adhesive. It features a dual curing component which reacts to atmospheric moisture. Thus shadow zones within the display frame can also be cured reliably.
Vitralit® UD 8540 exhibits excellent adhesion to glass and PMMA, which makes it the perfect solution to bond glass/glass or glass/PMMA displays. For bonding glass/PC a specially formulated version of this adhesive is available. Both adhesive variations are free of solvents and silicones.
Large-surface bonding or lamination of displays can be optimized by using Hoenle’s high-performance and energy efficient LED Spot 100 curing system. The LED Spot 100 is perfectly matched to the photoinitiators of Vitralit® UD 8540.The alignment of its LEDs ensures high intensity and homogenous light distribution, which is of utmost importance for display bonding. The LED Spot 100 heads can be mounted together without gaps to match the size of the display being bonded.
After curing Vitralit® UD 8540 is very soft with a hardness in the Shore 00 range. Thermal stresses between dissimilar substrates can be neutralized without causing delamination. The cured adhesive is transparent and non-yellowing.
Vitralit® UD 8540 is used for manufacturing displays
New Potting Compound With Excellent Flow Properties
Panacol has developed a new potting compound with medium viscosity and small filler particle size: Structalit® 5894-1 is the perfect choice for large-volume potting or glob top sealing of power electronics.
Structalit® 5894-1 is a one-component, black epoxy resin. During application it features optimum flow properties, due to its combination of optimized viscosity and small particle size of fillers. As an additional benefit, the low filler weight makes Structalit® 5894-1 less abrasive during application.
Structalit® 5894-1 cures rapidly when exposed to heat, which allows faster processing of large-volume electronic component potting and sealing. Once cured, the compound provides a smooth and level surface which is at the same time shock- and scratch-resistant.
Potting compound Structalit 5894-1 provides smooth and level surfaces
New black epoxy underfiller
Panacol has developed a new epoxy-based underfiller. Structalit® 8202 is a low viscosity one-part adhesive with a high capillary flow filling the narrowest gaps.
Structalit® 8202 is a high performance underfill material designed for chip stack packages and BGA. It is a one part, black colored epoxy with low viscosity which flows into the narrowest gaps. Special features of this product are its low coefficient of thermal expansion and high glass transition temperature. This makes Structalit® 8202 stable at high temperatures, allowing usage in reflow processes.
Structalit® 8202 cures rapidly under the influence of heat. The underfiller can also be cured during reflow processes. Due to its very good compatibility with most leadfree solders the adhesive cures completely even if it gets into contact with residues from flux agents.
Once cured, the material provides excellent mechanical properties to protect solder joints during thermal cycling. Structalit® 8202 is RoHS compliant and meets electronic grade standards (less than 900ppm Cl-).
New underfill Structalit® 8202 flows into the narrowest gaps
New, flexible adhesive for PEEK
Panacol has developed an extremely flexible adhesive, which adheres particularly well to hard to bond plastics including PEEK: Vitralit® UV 4802 is a one-component acrylic system that cures very fast when exposed to light.
Vitralit® UV 4802 is a light curing adhesive based on acrylate resin, which features excellent adhesion to many plastics such as PEEK, PEN and TPU, that are typically hard to bond with conventional adhesives. This adhesive also adheres very well to ceramics and glass. Vitralit® UV 4802 is highly resistant to heat: tests have shown that the adhesive keeps its soft and flexible characteristics even after being exposed to temperatures of 150°C for seven days. Thanks to its high flexibility the adhesive is perfectly suited for bonding thin and bendable materials.
Vitralit® UV 4802 is of pink colour and cures within seconds under a UV or visible light source. Both gas discharge lamps and LEDs like the LED SPOT 100 from Hoenle are suitable for curing. Once cured, the adhesive fluoresces which enables inspection of the bondline under black light.
New flexible and bendable adhesive for bonding PEEK
New low-odour high-performance adhesive from Panacol
Panacol has a new two-component high-performance structural adhesive in its product range: Penloc® GTN is an easy to process methyl acrylate based low-odour adhesive that can be used in a wide variety of applications.
Penloc® GTN adheres especially well to brass, ceramics, steel, aluminium, PVC and similar materials. The performance adhesive boasts a high power transmission capability and excellent thermal stability. It is both flexible and offers superior adhesion. Compared to other methyl acrylate adhesives, it has the advantages of a low odour formation and a long processing time of ten to 15 minutes.
To allow effective monitoring of blending quality, the two components of Penloc® GTN have different colours that, applied thinly, change to a grey, almost colourless surface as the blend cures. Penloc® GTN can be conveniently dispensed from a handy 50 ml double cartridge or from drums connected to dispensing apparatus.
Structural adhesive Penloc® GTN
New Medical Grade Epoxy Adhesive
Panacol adds epoxy-based adhesive Structalit® 8801 to its portfolio of medical grade adhesives. The biocompatible adhesive was specially designed for bonding temperature-sensitive substrates as it cures quickly at low temperatures.
Structalit® 8801 is a single-component adhesive based on epoxy resin. Due to its viscosity characteristics it is perfectly suited as a potting or filling material. The beige-coloured adhesive possesses high chemical resistance against common cleaning agents used for medical devices, including isopropyl alcohol. It develops high bond strength with ceramics, metals and many plastics. For example, Structalit® 8801 is successfully being used as a potting compound for sensors in medtech devices.
Structalit® 8801 cures very quickly at low oven temperatures. At 100°C this adhesive will fully cure in only a few minutes.
For applications in medical devices Structalit® 8801 is certified according to ISO 10993-5 standards. The adhesive is 100% solvent free and compatible with common sterilization processes such as autoclaving, gamma irradiation, E-beam and EtO.
Structalit® 8801 is used for potting of sensors
New super-fast curing SMD adhesive
Specially designed for attaching SMDs on circuit boards, Panacol has developed new fast curing epoxy adhesive Structalit® 5610. Due to its high viscosity the adhesive is well-suited for screen printing. The new adhesive will be first shown at this years’s Productronica in Munich.
Structalit® 5610 is a red-colored epoxy adhesive which makes a perfect contrast to green circuit boards. The one-component adhesive is easily applied via dispenser, screen printing or needle transfer.
The SMD adhesive cures thermally within minutes, even at low temperatures. At the same time it is highly temperature-resistant: Temporarily it can be exposed to temperatures up to 280° C, making it the perfect adhesive for reflow soldering.
Once cured, Structalit® 5610 is extremely shock-resistant and features very high adhesion to FR4 circuit boards, to metals and to epoxy-based mold materials.
For more information visit us at Productronica in Munich in hall A4, stand 465!
Download our brochure: Adhesive solutions for PCBs
Dots of Structalit® 5610 were applied via screen printing
New epoxy resin UV adhesive for dome coatings
At this year’s BondExpo, Panacol is presenting its latest development: Vitralit® UC 6686 – a UV-curing epoxy resin adhesive. Extremely hard and scratch-resistant, it is perfect for dome coatings and for decorating glass and plastics.
Vitralit® UC 6686 is an epoxy resin based single-component adhesive, which cures rapidly under UV light. Developed especially for dome coatings, its high viscosity makes it ideal for automatic dispensing and application with precise pattern.
Once cured, Vitralit® UC 6686 is extremely hard and scratch-resistant and has a transparent, brilliant high-gloss surface that does not yellow. It adheres especially well to glass, plastics and metals and has already been successfully used to in the decoration of glass perfume bottles.
The adhesive can be cured with both UV gas discharge lamps and UV LED lamps. Very good adhesion of applications over a large surface can be achieved with Hönle’s LED Spot 100 at a wavelength of 365 nm.
Visit us at the BondExpo in Stuttgart, Germany in Hall 6, Stand 6420!
Vitralit UC 6686 is well suited for applying decorative reliefs on glass bottles
Precision spraying of maskings and conformal coatings
The new preeflow® eco-SPRAY precision volume dispenser from ViscoTec makes for even and fast application of Panacol maskings and conformal coatings. The new technology yields perfect results with exceptional edge sharpness whether spraying low- or high-viscosity UV adhesives.
Spraying high-viscosity adhesives from Panacol onto large surfaces at more than 10,000 mPa becomes child’s play with the eco-SPRAY from ViscoTec: the new dispenser makes short work even of highly viscous and stable materials, such as Panacol’s liquid seal Vitralit® FIPG 60102 or masking compound Vitralit® MASK 20102, which is specially formulated for temporary coatings. The purely volumetric dosing of the eco-SPRAY system uses the endless piston principle to precisely meter and apply exact amounts regardless of their viscosity and supply pressure.
To achieve the required layer thickness, the applied amount can be changed simply by changing the air pressure, the adhesive volume, the distance to the substrate or the speed of application. The eco-SPRAY is intuitive in use and can be adapted to different materials and dosing processes with a range of supplied needle diameters and air caps.
Capable of handling viscous adhesives, the eco-SPRAY has also proven suitable for spraying and vaporizing low-viscosity conformal coatings. The two products used here were Vitralit® 2004 F and Vitralit® 2007 F – both dual-curing epoxy resin based adhesives. With the eco-SPRAY, both of these adhesives can be applied as surface coatings with high edge sharpness and cured in a continuous process with UV flood lamp, for example from Hönle’s UVAPRINT range. Here, the arc length can be ideally adapted to the PCB’s width.
Panacol's masking adhesives are easily sprayed with Viscotec's eco-SPRAY
New structural adhesive cures at low temperatures
Panacol introduces newly developed structural adhesive Structalit® 8801 T, which cures rapidly at low temperatures. The epoxy adhesive was specially formulated for temperature-sensitive applications in electronics, as well as automotive and aerospace industries.
Structalit® 8801 T is an all-purpose beige-colored single-component epoxy adhesive. It is ideally suited for potting applications in electronic components. Its excellent chemical resistance against oils and fuels makes it the perfect choice for bonding applications in the automotive and aerospace industry. Structalit® 8801 T has been successfully used in applications where strong resistance to hot kerosene and brake fluids was needed.
Due to its shear thinning properties Structalit® 8801 T offers improved flow control and the ability for precise dispensing on components surfaces. This adhesive develops high bond strength on ceramics, metals and many plastics.
Structalit® 8801 T cures very quickly at low oven temperatures. At 100°C this adhesive will fully cure in only a few minutes. Induction curing processes can be used to cure Structalit® 8801 T on ferromagnetic substances.
New shear-thinning adhesive Structalit 8801 T cures at low temperatures
New Glob Top adhesives
Specially for the consumer and general electronics industry, Panacol has developed two new adhesives with a low halogen content: Vitralit® UD 8050 and Structalit® 8838 provide encapsulation of electronic components on PCBs.
Vitralit® UD 8050 is an acrylic-based one-component adhesive which, thanks to its easy dispensing ability and rapid curing, is especially suitable for use in the consumer electronics sector, in which a high throughput is necessary.
Exposed to UV light, Vitralit® UD 8050 cures within seconds. Being dual UV and moisture curing, Vitralit® UD 8050 will also fully cure in shadowed areas not reached by the UV light, thereby increasing the performance of the hardened adhesive. For enhanced process control, a version with fluorescent marker is also available.
Structalit® 8838 is a black epoxy-based one-component adhesive. Its key characteristics are a low glass transition temperature, good flexibility and fast thermal curing. Once cured, Structalit® 8838 is the perfect solution for flexible encapsulation of electronic components. Temperature and moisture tests have proved that the adhesive does not impair the properties of individual components.
Both Vitralit® UD 8050 and Structalit® 8838 allow better flow control and precise dispensing on individual components due to their intrinsic viscosity. Both of these adhesives are compatible with fluxing agent and can therefore ensure full, effective curing on electronic components. With a low halogen content, they fulfil international electronic grade standards regarding corrosion prevention of electronic components.
A fluorescent version of dual curing adhesive Vitralit UD 8050
New UV-adhesive for elastomeric bonds
At the BondExpo in Stuttgart/Germany Panacol presents a new solvent free UV-adhesive. Vitralit® VBB-2N LV features low viscosity and is ideally suited for bonding elastomeric materials.
Due to its extremely low viscosity Vitralit® VBB-2N LV is suitable for large area bonding as well as applications where the gap size is very small. When cured, it demonstrates excellent flexibility and environmental stability. Vitralit® VBB-2N LV is a solvent-free transparent adhesive and provides very good adhesion to most elastomeric materials like TPE (Thermal Plastic Elastomer) and rubber (natural rubber latex, NBR, SBR etc).
If at least one assembly material is transparent, Vitralit® VBB-2N LV cures in seconds with UV-A light to produce a strong and reliable bond. UV-blocking materials like polycarbonate can be cured due to the adhesive’s ability to cure with visible light (>400nm). Both gas discharge lamps and LEDs are suitable for curing. Excellent curing results were achieved with the 405nm Blue Point LED light from Dr. Hoenle AG.
For use in medical applications Panacol can provide an alternative product with similar properties that meets the requirements for USP Class VI and is compatible with sterilization by autoclaving, gamma irradiation and EtO.
Panacol-Elosol GmbH, a member of the global Hoenle group, is an international supplier of adhesives with a broad product range that includes UV curable adhesives, structural adhesives, and conductive adhesives. Panacol is also a reliable provider of UV processing systems, supported by Dr. Hoenle AG. Hoenle is a global technology leader and manufacturer of industrial UV curing devices and systems. At BondExpo in Stuttgart, Panacol presents its high tech products for various applications.
Two substrates bonded with new UV-adhesive Vitralit® VBB-2N LV
New plastic adhesive with multiple viscosity options
Panacol introduces a newly developed UV adhesive, which is specially formulated for bonding plastics and will be available in three different viscosities.
The appropriate viscosity can be chosen depending on the application: Vitralit® 7311 is extremely low viscosity and thus the perfect choice for very tight bond gaps. Vitralit® 7311 T is a mid-range viscosity version, and Vitralit® 7311 Gel features high viscosity, non-flowing properties.
All three variations of Vitralit® 7311 provide excellent adhesion to most plastics like PC, PVC and PMMA, as well as to metal and glass. Vitralit® 7311 is transparent and non-yellowing. It is resistant to alcohols and humidity. Once cured, the adhesive will be visco-plastic. For use in medical applications Vitralit® 7311 is currently being tested according to USP Class VI and DIN ISO 10993-4/-5 standards.
Vitralit® 7311 cures in seconds with ultraviolet or visible light. For excellent curing results high intensity LEDs at 405 nm wavelength are recommended. This wavelength also permits the bonding of UV blocked materials like polycarbonate. Vitralit® 7311, as an example, can be utilized for needle bonding in medical device manufacturing. Cured with a Bluepoint LED eco light source from UV manufacturer Hönle, Vitralit® 7311 achieves high bond strength in less than a second, providing reliable and durable bonds.
Vitralit® 7311 is the perfect choice for bonding needles
New UV-adhesive for plastic bonds
At the Medtec show in Stuttgart/Germany Panacol presents a new adhesive from its successful Vitralit® UV 4050s series: Vitralit® UV 4050 MV features medium viscosity and is best suited for bonding plastics, especially for medtech applications.
With 450 to 650 mPas Vitralit® UV 4050 MV is of medium viscosity. When cured it shows a very good flexibility and an excellent stability. This transparent adhesive has a very low shrinkage of only 2%.
The newly developed adhesive provides excellent adhesion to most plastics like PVC, ABS, SAN and PC, as well as to stainless steel and glass. If at least one assembly material is transparent, Vitralit® UV 4050 MV will cure very quickly to produce a strong and reliable bond. UV blocked materials like polycarbonate can be cured thanks to the adhesive’s ability to cure with visible light (>400nm).
Vitralit® UV 4050 MV cures in seconds with UV-A and visible light. Both gas discharge lamps and LEDs are suitable to use for curing. Excellent curing results were achieved with LED lights with a wavelength of 405 nm. Vitralit® UV 4050 MV is currently being tested according to USP Class VI and DIN ISO 10993-4/-5 standards for use in medical applications.
New light curing adhesive Vitralit® UV 4050 MV features excellent adhesion to plastics and polycarbonate
New jettable conductive adhesives
Panacol recently expanded its Elecolit®-product portfolio. Thanks to new, innovative filling materials and optimized hardener systems, newly developed adhesives with improved conductivity are now available. For maximimum processing speed, these adhesives can be applied by jetting. New hardener systems in many of the one part epoxy based adhesives develop cure within minutes.
The new Elecolit® silver filled adhesives are available in a range of viscosities to accommodate various applications and requirements. As the conductivity is strongly dependent on the content of conductive filler, Panacol uses uniquely shaped filling materials to achieve an optimal fill ratio. This ensures high conductivity and consistent product performance.
Jetting conductive Elecolit® adhesive
New low-viscosity uv- and visible light-curing adhesive
Vitralit® UV 4050 LV is a newly developed adhesive with extremely low viscosity and thus the perfect choice for very tight bond gaps. It provides excellent adhesion to most plastics like PC, PVC, PS, ABS, SAN as well as to metals like stainless steel, steel or aluminum and glass. If at least one assembly material is transparent, Vitralit® UV 4050 LV will cure very quickly to produce a strong and reliable bond. The ability to cure with visible light (>400nm) permits the bonding of UV blocked materials like polycarbonate. Vitralit® UV 4050 LV is currently being tested according to USP Class VI and DIN ISO 10993-4/-5 standards for use in medical applications.
Vitralit® UV 4050 LV cures in seconds with UV-A and visible light. Both gas discharge lamps and LEDs are suitable to use for curing. High intensity gallium doped gas discharge lamps produce excellent curing results.
Vitralit® UV 4050 LV is the perfect choice to bond transparent tube sets with tight bond gaps
New dual curing adhesive
Vitralit® UD 2018 is a thixotropic epoxy adhesive with extremely low shrinkage. It can be dispensed very precisely with accurate bead dimensions, making it the perfect choice for micro dispensing in electronic applications, such as fixing SMDs or transceivers on PCBs.
Typically, Vitralit® UD 2018 comes in a pink and fluorescent version. It cures with traditional UV-A discharge lamps or 365 nm LED-light. Any shadowed areas can be post cured thermally.
The adhesive offers all the benefits of epoxy resins: It is highly resistant to environmental stresses, and can better withstand the effects of wide temperature excursions and moisture. This makes Vitralit® UD 2018 the perfect solution for bonding SMDs and electronic components which are frequently subjected to temperature variations and thermal shock.
Dual cure adhesive Vitralit® UD 2018 can be accurately dispensed
Panacol Expands Adhesive Portfolio for Medical Applications
Adhesive Structalit® 5893 is Panacol’s latest addition to its portfolio of medical grade adhesives. The black epoxy potting compound has been specially formulated for bonding metals and stainless steel. Structalit® 5893 has already proved successful as a black encapsulant in electronic applications, as well as for bonding and encapsulating injection devices for veterinary medicine. The adhesive is based on epoxy resin with excellent resistance to moisture and thermo-shock.
Germany-based Panacol-Elosol GmbH, a member of Hoenle Group, is a leading manufacturer of industrial and medical grade adhesives.
Visit us at Medtec Europe from 21 to 23 April 2015 in Stuttgart at stand no. 7C 28!
New Medical Grade Adhesive
Panacol presents new medical grade adhesive Vitralit® 7041 MV at this year’s Compamed in Duesseldorf, Germany: Panacol’s latest addition to its medical grade adhesives portfolio is Vitralit® 7041 MV.
The adhesive has a USP Class VI-certification and has been successfully tested in needle bonding applications. Vitralit® 7041 MV is an acrylate which shows very high adhesion to polycarbonate and is thus very suitable for needle bonding, reservoir assembly, bonding dialysis filters, and bonding of connectors and IV tube sets.With a viscosity range from 200 to 400 mPas, Vitralit® 7041 MV can be used in a variety of bond gaps and joint configurations. For an optimum process control, the adhesive is also available in a fluorescent version, Vitralit® 7041 MV F, which is also certified USP Class VI. Vitralit® 7041 MV can be cured with either UV- or LED-light. The quickest curing results were achieved with 405 nm LEDs.
Vitralit® 7041 MV is specially formulated for bonding needles into plastic oder glass syringes
Panacol presents its LED-curing epoxy adhesives at this year's BondExpo trade fair in Stuttgart, Germany. Thanks to the development of new photoinitiators, Panacol is now able to produce new adhesive materials that are based on highly resilient epoxy resins. They can be fully cured within seconds with many of today’s UV-LED light curing systems.
An epoxy adhesive is cured with LED light
